    Product Name : Tubular Solenoid
    Product No : RG-T-1130L
    Inquiry
    Product Introduction



    ▪ Plunger Weight:3.2g

    ▪ Total Weight: 17g

    ▪ COIL DATA

    Heat Sink: 25 x 25 x 3mm(alumimum)

    Duty cycle(%)= X 100%Continuous (100%)Or less(50%)Or less(25%)Or less(10%)
    MAX. "on" time in seconds 50 5 2
    Watts at 20°C 4 8 16 40
    Ampere-turns at 20°C 497 704 994 1573
    Type no.Resistance (20°C) ¡Ó10%No. turnsVolts DC
    RG-T-1130L06AA 9 745 6 8.5 12 19
    RG-T-1130L12AA 36 1492 12 17 24 38
    RG-T-1130L24AA 144 2972 24 34 48 76
    RG-T-1130L48AA 576 5850 48 68 96 152
