    Product Name : Push-Pull Solenoid
    Product No : RG-T-4122SL
    Inquiry
    Product Introduction



    ▪ Plunger Weight:3g

    ▪ Total Weight: 18g

    ▪ COIL DATA

    Heat Sink: 160 x 160 x 3mm(alumimum)

    Duty cycle(%)= X 100%Continuous (100%)Or less(50%)Or less(25%)Or less(10%)
    MAX. "on" time in seconds 100 36 9
    Watts at 20°C 12.5 25 50 125
    Ampere-turns at 20°C 714 1000 1425 2250
    Type no.Resistance (20°C) ¡Ó10%No. turnsVolts DC
    RG-T-4122SL06AA 2.88 343 6 8.5 12 19
    RG-T-4122SL12AA 11.5 685 12 17 24 38
    RG-T-4122SL24AA 46 1369 24 34 48 76
    RG-T-4122SL48AA 184 2737 48 68 96 152
