    Product Name : Push-Pull Solenoid
    Product No : RG-T-5936SL
    Inquiry
    Product Introduction



    ▪ Plunger Weight:145g

    ▪ Total Weight: 620g

    ▪ COIL DATA

    Heat Sink: 310 x 310 x 3mm(alumimum)

    Duty cycle(%)= X 100%Continuous (100%)Or less(50%)Or less(25%)Or less(10%)
    MAX. "on" time in seconds 87 36 13
    Watts at 20°C 32 64 128 320
    Ampere-turns at 20°C 1480 2080 2940 4620
    Type no.Resistance (20°C) ¡Ó10%No. turnsVolts DC
    RG-T-5936SL06AA 1.13 278 6 8.5 12 19
    RG-T-5936SL12AA 4.5 555 12 17 24 38
    RG-T-5936SL24AA 18 1110 24 34 48 76
    RG-T-5936SL48AA 72 2220 48 68 96 152
