Open Frame Solenoid
    Enlargement
    Product Name : Open Frame Solenoid
    Product No : RG-O-0626S
    Inquiry
    Product Introduction



    Plunger Weight: 5g

    Total Weight: 43g

    COIL DATA

    Duty cycle(%)= X 100%Continuous(100%)Or less(50%)Or less(25%)Or less(10%)
    MAX. "on" time in seconds 55 19 3
    Watts at 20°C 2.1 4.2 8.4 21
    Ampere-turns at 20°C 428 605 856 1353
    Type no.Resistance (20°C)?0%No. turnsVolts DC
    RG-O-0626L06AA 17.1 1220 6 8.5 12 19
    RG-O-0626L12AA 68.6 2447 12 17 24 38
    RG-O-0626L24AA 274 4886 24 34 48 76
    RG-O-0626L48AA 1097 9782 48 68 96 152
